PCAN-Router Pro – User Manual
on your computer in order to transfer them to the PCAN-
Router Pro after the firmware update.
8.3
Sending the Firmware
The process of uploading new firmware to the PCAN-Router Pro
is as follows:
1.
Turn on the PCAN-Router Pro by applying a supply voltage.
BL-HW: The "μC Status" LED stays off, the LEDs of the
CAN connectors CAN 1 to CAN 4 are blinking.
2.
Run the program PcanFlash.exe under Windows from the
local hard drive.
3.
Click on the
box.
4.
From the Hardware Profile dropdown list, select the PCAN-
Router Pro entry.
(Options) button in order to call up the dialog
45
