Peak PCAN-Router Pro User Manual page 38

PCAN-Router Pro – User Manual
For further use of the trace data proceed as follows:
1. Eject the CF card from the PCAN-Router Pro and insert it
into the card reader of the computer.
2. From the provided DVD, start the converter program PEAK-
Converter.exe located in the directory Tools/PCAN-
Router Pro/Tools/PEAK-Converter.
3. As source select the file trace.btr from the CF card.
4. Specify a destination file and select the desired target
format (see above). Do not save the destination file to the CF
card.
38
