PCAN-Router Pro – User Manual
PPCAN-Editor - References (PDF file):
Explains the function blocks and the mathematical functions that
are implemented in PPCAN-enabled devices (like the PCAN-
Router Pro).
1.1

Properties at a Glance

4 High-speed CAN channels via pluggable transceiver modules
(Wake-up capability); alternatively, Low-speed, Single-wire, and
opto-decoupled High-speed modules, as well as High-speed
modules without wake-up function available
Wake-up via a separate input or the CAN bus
Complies with CAN specifications 2.0 A/B
CAN connection D-Sub, 9-pin
CAN termination switchable, separately for each CAN channel
Slot for CompactFlash card
Battery-buffered real-time clock (RTC), can also be used for
wake-up
Beeper
Status LEDs for CAN channels, CompactFlash card,
microcontroller, and power supply
NXP LPC2294 microcontroller
Aluminum casing with flange; DIN rail fixing option available on
request
Voltage supply from 8 to 27 V, protection against overvoltage
and reverse polarity
Extended operating temperature range from -40 to +85 °C (-40 to
+185 °F)
6
