PCAN-Router Pro – User Manual
The D-Sub connectors have pins with additional functions:
Connectors
CAN 1, CAN 2,
CAN 3, CAN 4
CAN 3, CAN 4
CAN 3, CAN 4
Note: The additional functions at the D-Sub connectors are not
galvanically isolated. When using the transceiver module
HSGE2, galvanic isolation is only provided for those pins that
are assigned to CAN communication at the corresponding D-
Sub connector (2: CAN_L, 7: CAN_H, 3: CAN_GND).
2.3

CompactFlash Card

To log the CAN data traffic (trace) you can use CompactFlash cards
(CF cards) with a maximum capacity of 2 GByte.
The CF slot is located on the rear of the PCAN-Router Pro. The CF
card is properly inserted if it flushes with the rear panel.
Note: When you want to insert or eject a CompactFlash card,
the PCAN-Router Pro must be turned off (no power supply or
power-down mode, Power LED off). Else the card is not
detected or data gets lost.
About the use of a CF card see chapter 6
CompactFlash Card
Pin Function
1 5-Volt supply for external devices (to be
activated on the circuit board)
4 Input for external wake-up signal
9 Supply of the router via a D-Sub
connector (to be activated on the circuit
board)
on page 34.
Logging CAN Traffic onto a
11
See section...
3.4 on page 17
5.7.3 on page 32
3.5 on page 18
