PCAN-Router Pro – User Manual
Choice of the hardware profile for the PCAN-Router Pro
4. Follow the remaining instructions of the setup program.
You can then launch the PPCAN-Editor, create a configuration, and
send it to the PCAN-Router Pro. Find relevant information in the
help of the PPCAN-Editor.
Note: The PPCAN-Editor uses the CAN ID 7E7h for communi-
cation with the PCAN-Router Pro. Using the standard firmware,
it is defined for each CAN channel that the PCAN-Router Pro is
reacting to incoming configuration messages. Therefore, do not
use CAN ID 7E7h otherwise, or switch this behavior on or off
for the single CAN channels (I/O function
Configuration ID 07e7h Enable
70h Special Out >
).
