Xenus
cMe2 & axIs b I/o connectIons
CME2 SCREEn FoR inPUTS [in11~in20]
inPUT DATA
input Pin R1
in11 J12-12 10k
in12 J12-13
in13 J12-14
10k
in14 J12-15
in15 J12-30
in16 J9-7
in17 J9-8
in18 J9-9
in19 J9-18
iCoM2 J9-17
4.99k
in20 J11-7
in22 J11-24 10k
Hi/lo DEFiniTionS: inPUTS
input State Condition
Hi Vin >= 2.5 Vdc
in11,20,22
lo Vin <= 1.3 Vdc
Hi Vin > 2.5 Vdc
in12~15
lo Vin < 2.5 Vdc
Hi input diode on
in16~19
lo input diode oFF
IN16~19 are optically isolated and work from
positive or negative input voltages. When voltage
is applied to an input and current flows through the
input diode of the opto-coupler the diode condition
is on. When no voltage is applied to an input and
no current flows through the input diode it is OFF.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Web: http://www.copleycontrols.com
PLUS
R2 C1
10k 100p
1k 100p
+30Vmax
+24V typical
+24V
Vmax
opto
+5V
10k 33n
10k 100p
inPUTS WiTH
PROGRAMMABlE
PUll UP/DoWn
input
in11
in12
in13
in14
in15
2-Axis CANopen
[in11]
PullUp = 5V
+5V
PullDown = 0V
74HC14
10k
[INx]
10k
100p
[in12~15]
J12 Control
12V
+5V
10k
1k
[IN2,4,12,14]
100 pF
+5V
10k
1k
[IN3,5,13,15]
100 pF
[in20]
Pin PU/PD
J12-12 5
[INx]
J12-13 6
J12-14 7
J12-15
8
J12v-30
Tel: 781-828-8090
XP2
Rev 01
[in16~19]
24V GND
24V
+
MAX3096
2.5V
+ +
24V
MAX3096
[in22]
+5V
74HC2G14
4.99k
[INx]
10k
33n
Fax: 781-828-6547
Page 20 of 34
RoHS
J9
[COMM2]
17
4.7k
[IN16]
7
4.99k
5.1V
4.7k
[IN17]
8
4.99k
5.1V
4.7k
[IN18]
9
4.99k
5.1V
4.7k
[IN19]
18
4.99k
5.1V
+5V
74HC14
10k
10k
100p
