Copley Controls Xenus Plus XP2 Series Manual page 14

Xenus
Motor connectIons: encoder & resolVer
Motor connections are of three types: phase, feedback, and thermal sensor. The phase connections carry the drive output currents that
drive the motor to produce motion. A thermal sensor that indicates motor overtemperature is used to shut down the drive to protect the
motor. Feedback can be digital quad A/B encoder, analog sin/cos encoder, resolver or digital Halls, depending on the version of the drive.
QUAD A/B EnCoDER WiTH FAUlT PRoTECTion
Encoders with differential line-driver outputs are required (single-ended encoders are not supported) and provide incremental position feedback via
the A/B signals and the optional index signal (x) gives a once per revolution position mark. The MAx3097 receiver has differential inputs with fault
protections for the following conditions:
Short-circuits line-line:
Open-circuit condition:
Low differential voltage detection:
±15kV ESD protection:
Extended common-mode range:
ConnECTionS WiTH A/B/X EnCoDER
Encoder
J10, J11
FG Frame Ground
A
A
121
/A
B
B
121
/B
X
Z 130
/X
+5V
+5V Out @ 500 mA
0V Signal Ground
SHiElDED CABlE ConnECTionS
Double-shielded cable is recommended for resolvers and analog sin/cos encoders. The outer shield connects to the motor and drive
frames. The inner shield(s) should only connect to the Signal Ground at the drive. The inner shields shown here are for individually
shielded twisted-pair cables. If the inner shield is a single one, it connects to Signal Ground at the drive.
The inner shield should have no connection at the motor, or the the outer shield. Double-shielding is used less frequently for digital
encoders, but the connections are shown here and on following pages for completeness.
ANAlOG SIN/COS INCREMENTAl ENCODER
The sin/cos/idx inputs are differential with 121 Ω terminating
resistors and accept 1 Vp-p signals in the format used by
incremental encoders with analog outputs, or with
motors.
J10, J11
Encoder
FG Frame Ground
Sin(+)
sin
Sin(-)
Cos(+)
cos
Cos(-)
Idx(+)
indx
Idx(-)
+5V
+5V Out @ 500 mA
0V Signal Ground
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Web: http://www.copleycontrols.com
PLUS
This produces a near-zero voltage between A & /A which is below the differential fault threshold.
The 121Ω terminator resistor will pull the inputs together if either side (or both) is open.
This will produce the same fault condition as a short-circuit across the inputs.
This is possible with very long cable runs and a fault will occur if the differential input voltage is < 200mV.
The 3097E has protection against high-voltage discharges using the Human Body Model.
A fault occurs if the input common-mode voltage is outside of the range of -10V to +13.2V
A/B/x SIGNAlS
Signal
Enc A
Enc /A
Enc. A
Enc B
Enc /B
Enc X
Enc. B
Enc /X
+5V
1k
+5V
Enc. Index
Sgnd
1k
Shld
ServoTube
SIN/COS SIGNAlS
Signal
10k
-
Sin(+)
121 Sin
Sin(-)
+
10k
Cos(+)
10k
Cos(-)
-
Cos
121
Idx(+)
+
10k
Idx(-)
1k
+5V
+5V
Indx
121
Sgnd
1k
Shld
2-Axis CANopen
CONNECTIONS WITH NO INDEx SIGNAl
Encoder
J10,J11
Pin
13
12
A
11
10
9
B
8
6
5
1 Z
+5V
RESOlVER (-R MODElS)
Resolver set up, motor phasing, and other commissioning
adjustments are made with CME 2 software. There are no
hardware adjustments.
Resolver
J10,J11
FG
Pin
19
18
21
Sin
S3 S1
S2
20
Cos
23
S4
R2 Ref R1
22
17
16
1
Tel: 781-828-8090
XP2
Rev 01
J10, J11
FG
Frame Ground
A
121
/A
B
121
/B
X
130
/X
+5V Out @ 500 mA
0V Signal Ground
J10, J11
Frame Ground
Sin(+) S3
Sin(-) S1
R/D
Conversion
Cos(+) S2
Cos(-) S4
Ref(+) R1
Ref(-) R2
Signal Ground
RoHS
Enc. A
Enc. B
+5V
1k
Enc. Index
1k
RESOlVER SIGNAlS
J10,J11
Signal
Pin
Sin(+) S3 19
Sin(-) S1 18
Cos(+) S2 21
Cos(-) S4 20
Ref(+) R1 23
Ref(-) R2 22
+5V 17
Sgnd 16
Shld 1
Fax: 781-828-6547
Page 14 of 34
