Copley Controls Xenus Plus XP2 Series Manual page 19

Xenus
cMe2 & axIs a I/o connectIons
CME2 SCREEn FoR inPUTS [in1~in10]
inPUT DATA
input Pin R1
in1 J12-7
10k
in2 J12-8
in3 J12-9
10k
in4 J12-10
in5 J12-11
in6 J10-2
in7 J10-3
in8 J10-4
in9 J10-5
iCoM1 J10-6
in10 J11-7 4.99k
in21 J11-24 10k
Hi/lo DEFiniTionS: inPUTS
input State Condition
Hi Vin >= 2.5 Vdc
in1,10,21
lo Vin <= 1.3 Vdc
Hi Vin > 2.5 Vdc
in2~5
lo Vin < 2.5 Vdc
Hi input diode on
in6~9
lo input diode oFF
IN6~9 are optically isolated and work from positive
or negative input voltages. When voltage is applied
to an input and current flows through the input
diode of the opto-coupler the diode condition is
on. When no voltage is applied to an input and no
current flows through the input diode it is OFF.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Web: http://www.copleycontrols.com
PLUS
R2 C1
10k 100p
1k 100p
+30Vmax
+24V typical
+24V
Vmax
+5V
opto
10k 33n
10k 100p
inPUTS WiTH
PROGRAMMABlE
PUll UP/DoWn
input
in1
in2
in3
in4
in5
2-Axis CANopen
[in1]
PullUp = 5V
+5V
PullDown = 0V
74HC14
10k
[INx]
10k
100p
[in2~5]
J12 Control
12V
+5V
10k
1k
[IN2,4,12,14]
100 pF
+5V
10k
1k
[IN3,5,13,15]
100 pF
[in10]
Pin PU/PD
[INx]
J12-7 1
J12-8 2
J12-9 3
J12-10
4
J12-11
Tel: 781-828-8090
XP2
Rev 01
[in6~9]
24V GND
24V
+ 6
2
3
MAX3096
4
2.5V
5
+
+
24V
MAX3096
[in21]
+5V
74HC2G14
4.99k
[INx]
10k
33n
Fax: 781-828-6547
Page 19 of 34
RoHS
J9
[COMM1]
4.7k
[IN6]
4.99k
5.1V
4.7k
[IN7]
4.99k
5.1V
4.7k
[IN8]
4.99k
5.1V
4.7k
[IN9]
4.99k
5.1V
+5V
74HC14
10k
10k
100p
