Specifications

This chapter contains the technical specifications for the RotoRest system, as well as data on
replacement parts.

Technical Specifications

Equipment not suitable for use in the presence of a flammable anesthetic
mixture with air, oxygen or nitrous oxide.
When using half-bed-length type oxygen administering equipment, ensure
that side rails are not contained in oxygen enriched environment.
Type B device
Class II device
Standard device
Maximum recommended patient weight ......................................... 150 kg
Maximum recommended patient height (see page 3) ................ 190 cm

Dimensions

Length ............................................................................................................ 2475 mm
Height of bed frame
(when bed is in lowered position) ........................................................ 1250 mm
Height of patient support surface
(when bed is in lowered position) ........................................................ 884 mm
Weight ............................................................................................................ 415 kg
Ground clearance
(platform raised) ......................................................................................... 110 mm
Ground clearance
(platform lowered) ..................................................................................... 90 mm

Functional specifications

Rotation angle ............................................................................................. 0° to 62° in both directions
Trendelenburg (maximum) .................................................................... 11°
Reverse Trendelenburg (maximum) .................................................... 11°

Electrical specifications

Voltage ........................................................................................................... 230 V alternating current
Frequency ..................................................................................................... 50 Hz
Current rating (ampere) (rotation only) ............................................. 1.0 A
Current rating (ampere) (lowering / lifting hydraulics) ................ 4.6 A
Leakage current (microampere) ........................................................... <100 µA
Isolating transformer................................................................................. 1 KVA
Ground resistance (ohm) ......................................................................... <0.1 Ω
Noise level ..................................................................................................... <70 dB (A)
Duty cycle...................................................................................................... Continous (rotation)
Specifications are subject to change without notice.
