The Operating Unit

The bed has a menu-controlled operating unit, which is used as follows. Please also refer to
the menu structure diagram.

Operating Display

Once the bed is switched on, the operating display appears on the screen.
The screen illustrated in the example shows the bed rotating to the left (flashing arrow).
62°
Timed out
The maximum rotation angle for the left side is set to 62° and for
the right side to 59°. In this example, the bed has been rotated for 24 minutes.

Menu Screen

To open the menu screen, press the Menu / Select button.
The cursor buttons enable you to move the cursor within this screen.
> Operating display
Set angle
Set holding time
Display Status
The menu is displayed for 15 seconds; if no other button is pressed during this time,
the display reverts to the operating display screen.
< 23° 59°
00:24
