3. Remove the side arm supports by pulling them off the bed in a vertical direction.
4. Place all side supports in the outermost lateral position before removing them. This
makes them easier to re-attach and adjust at a later time.
Loosen the locking lever for the thorax supports on the underside of the bed.
■
Apply pressure to the top of the pad and to the locking lever for the support
■
pad located beneath the bed at the same time.
Arm supports
5. Loosen the restraints for the shoulder retainers and rotate the
retainers by 100°.
Restraints
Shoulder
retainer
Crossbeam
Thorax supports
Hip / leg supports
11
