Zeroing the Timer

Lock the bed in the horizontal position. Make sure that the lock pin is pushed all the way in and
that the screen displays, Bed Locked.
1. Press the Menu / Select button to view the menu screen. Move arrow to, Display
Status, and press the Menu / Select button.
Operating display
Set angle
Set holding time
> Display Status
2. With arrow positioned at, Rotation Time, press Menu / Select button.
> Rotation time
Trendelenburg angle
Holding time
Press the down cursor key ↓ three times (the > arrow will disappear).
3.
Patient
Rotation
Stationary
4. Press the Menu / Select button to view the following screen.
Patient
Rotation
Stationary
After 15 seconds, the display will revert to the menu screen and the word, Charging, will
appear.
0017:42
0014:21
0003:21
0000:00
0000:00
0000:00
