5.2.2 DC input chokes

Size
2075
2110
3150
3185
3220
4300
4370
4450
5550
5750
Note!
The DC input choke is not integrated and can not be connected on ADP200-5S550 / ADP200-5S750 sizes.

5.3 AC output chokes

The ADP200 inverter can be used with standard motors or motors designed specifically for use with inverters.
The latter usually have a higher isolation rating to better withstand PWM voltage. Examples of reference regulations
are provided below: motors designed for use with inverters do not require any specific filtering of output from the
inverter. For standard motors, especially with long cable runs (typically over 100 m) an output choke may be necessary
to maintain the voltage waveform with the specified limits.
The range of recommended chokes are listed in the following table. The rated current of the chokes should be approx.
20% higher than that of the inverter in order to take into account additional losses due to modulation of the output
waveform.
Size
2075
2110
3150
3185
3220
4300
4370
4450
5550 / 5S550
5750 / 5S750
Note!
With the inverter operated at the rated current and a frequency of 50 Hz, the output chokes cause a voltage drop of approx. 2% of the output voltage.
I
n
(@400V/50Hz, with DC
THD (%)
input chokes)
(A)
16
21
< 35 %
28
35
40
45
40
45
50
40
Model
LU3-011
LU3-011
LU3-015
LU3-022
LU3-022
LU3-030
LU3-037
LU3-055
LU3-055
LU3-090
ADP200 • Quick installation guide - Specifications and connection
Model Code
LDC-007 S7AI12
LDC-011 S7AI13
LDC-015 S7AI14
LDC-022 S7AI15
LDC-022 S7AI15
Internal choke
Dimensions: WxHxd
Code
mm [inches]
S7FG4 180 x 185 x130
S7FG4 180 x 185 x130
S7FH2 180 x 185 x140
S7FH3 180 x 185 x160
S7FH3 180 x 185 x160
S7FH4 180 x 185 x170
S7FH5 180 x 185 x170
S7FH6 240 x 216 x170
S7FH6 240 x 216 x170
S7FH10 180 x 165 x195
Dimensions: WxHxd
mm [inches]
125 x 122 x 127 [4.92 x 4.8x5]
125 x 142 x 127 [4.92 x 5.59 x 5]
125 x 152 x1 27 [4.92 x 5.98 x 5]
155 x 148 x 160 [4.92 x 5.82 x 6.3]
155 x 148 x 160 [4.92 x 5.82 x 6.3]
Weight
kg [lbs]
8 [17.64]
8 [17.64]
7 [15.43]
8.2 [18.08]
8.2 [18.08]
10 [22.05]
10 [22.05]
16 [35.27]
16 [35.27]
15 [33.07]
Weight
kg [lbs]
4.9 [10.8]
6.6 [14.55]
8 [17.63]
8.5 [18.74]
8.5 [18.74]
