SECTION 2: Scanning, Mode and Setting Adjustments
2.6.2 Range and Sensing
Setting adjustment allows user to change sensing distances or tun off
sensing beams. This includes four presets and fine adjustments to both
upper and/or lower beam settings. These setting adjustments may be
necessary to troubleshoot detection issues. See section 4 for more details.
Chicago Faucets Commander Handheld Programming Unit User Guide
® ™
Range Adjustments Choose
—
"Factory (7")" pre-set for default
sensing distance.
Choose other "pre-sets" to
specify shorter or longer sensing
distances.
Make "fine adjustment" to
pre-sets using slider bar from
-2" to +2" relative to pre-set.
Beam Settings — Choose
one or both beams to turn "on"
(default), set to Dynamic Mode
or turn "off". See Section 4 for
more details concerning when
and how to use.
Tap "SET" to save and
Set —
execute setting
