Finding parts and locations
Locate physical part locations and identify parts with system diagrams.
Locate the FRU
Use the graphics and tables to locate the field-replaceable unit (FRU) and identify the FRU part number.
8001-22C or 8005-22N locations
Use this information to find the location of a FRU in the system unit.
Rack views
The following diagrams show field-replaceable unit (FRU) layouts in the system. Use these diagrams with
the following tables.
Figure 9. Front view
Table 37. Front view locations
Index number
1
2
3
4
5
6
© Copyright IBM Corp. 2016, 2019
FRU description
HDD 0
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
FRU removal and replacement
procedures
See Removing and replacing a
storage drive in the 8001-22C or
8005-22N.
See Removing and replacing a
storage drive in the 8001-22C or
8005-22N.
See Removing and replacing a
storage drive in the 8001-22C or
8005-22N.
See Removing and replacing a
storage drive in the 8001-22C or
8005-22N.
See Removing and replacing a
storage drive in the 8001-22C or
8005-22N.
See Removing and replacing a
storage drive in the 8001-22C or
8005-22N.
87
