Power Systems
Installing the IBM Power System
S822LC for Big Data (8001-22C)
IBM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8001-22C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBM 8001-22C

Summary of Contents for IBM 8001-22C

  • Page 1 Power Systems Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 3 Power Systems Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 4 Note Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on page 109, the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823. ™...

  • Page 5: Table Of Contents

    . Adapter PCIe x8 LP (FC EKAP) . 64 Installing a disk drive in the 8001-22C system . Qlogic QLE2692OP Dual-port 16 Gb Fibre Installing a drive on module in the 8001-22C Channel Adapter PCIe3 x8 LP (FC EKAQ) .
  • Page 6 8005-22N . . 104 Class B Notices . . 116 Placing an 8001-22C or 8005-22N system into Terms and conditions . . 119 the service position . . 104 Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 7: Safety Notices

    Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v If IBM supplied the power cord(s), connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.
  • Page 8 In addition, do not lean on rack mounted devices and do not use them to stabilize your body position (for example, when working from a ladder). Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 9 v Each rack cabinet might have more than one power cord. – For AC powered racks, be sure to disconnect all power cords in the rack cabinet when directed to disconnect power during servicing. – For racks with a DC power distribution panel (PDP), turn off the circuit breaker that controls the power to the system unit(s), or disconnect the customer’s DC power source, when directed to disconnect power during servicing.
  • Page 10 DANGER: Hazardous voltage, current, or energy levels are present inside any component that has this label attached. Do not open any cover or barrier that contains this label. (L001) (L002) viii Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 11 DANGER: Rack-mounted devices are not to be used as shelves or work spaces. (L002) (L003) Safety notices...
  • Page 12 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) (L007) CAUTION: A hot surface nearby. (L007) (L008) Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 13 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call. (C003)
  • Page 14 Power and cabling information for NEBS (Network Equipment-Building System) GR-1089-CORE The following comments apply to the IBM servers that have been designated as conforming to NEBS (Network Equipment-Building System) GR-1089-CORE: Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 15 The equipment is suitable for installation in the following: v Network telecommunications facilities v Locations where the NEC (National Electrical Code) applies The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed wiring or cabling only. The intrabuilding ports of this equipment must not be metallically connected to the interfaces that connect to the OSP (outside plant) or its wiring.
  • Page 16 Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 17: Installing And Configuring Power8 Processor-Based Systems And System Features

    (Publication number: SC27-6601-00) that is available from the IBM Publications Center (http://www-05.ibm.com/e-business/linkweb/publications/servlet/pbi.wss). This bulletin provides a list of the key IBM system installation activities and a list of activities that might be billable. Installing the system Learn how to install, cable, and set up your 8001-22C system.

  • Page 18: Determining And Marking The Location In The Rack For The 8001-22C System

    EIA unit of height. This system unit, therefore, is 89 mm (3.5 in.) high and covers six mounting holes in the rack. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 19: Attaching The Rails To The System Chassis And To The Rack

    3. If necessary, remove the filler panels to allow access to the inside of the rack enclosure where you plan to place the unit, as shown in Figure 1. Figure 1. Removing the filler panels 4. Determine to place the system in the rack. Record the EIA location. 5.
  • Page 20 Secure the inner chassis slide rail to the system chassis by using two screws (C). b. Repeat this step for the left chassis slide rail. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 21: Installing The System Into The Rack And Connecting And Routing Power Cables

    4. Move to the front of the rack. Align the left rack rail inside the rack cabinet by resting the rail bracket hooks on the rack flange holes that you previously marked. The rail hooks should be located in the flange hole in the middle of each EIA rack unit. 5.

  • Page 22: Completing Server Setup

    3. You can receive important technical information and updates for specific IBM Support tools and resources by subscribing to receive updates. To subscribe to receive updates, complete the following steps: a.

  • Page 23: Installing Drives In The 8001-22C System

    Notes for thermal limitations: v If the 8001-22C system has no GPUs, the system can support up to twelve 3.5-inch drives. The ambient temperature must not be more than 35°C (95°F). If all twelve 3.5-inch drives are installed, the system limits the 10-core POWER8 processor to 234 W and the 8-core POWER8 processor to 204 W.
  • Page 24 SATA Drives The 8001-22C system with feature codes EKB1 or EKB5 can support up to eight SATA drives. The drives supported drops to six if the system has a GPU. The drives are directly connected to the SATA ports and controller on the system backplane.

  • Page 25: Installing A Disk Drive In The 8001-22C System

    Notes for thermal limitations: v If the 8001-22C system has no GPUs, the system can support up to twelve 3.5-inch drives. The ambient temperature must not be more than 35°C (95°F). If all twelve 3.5-inch drives are installed, the system limits the 10-core POWER8 processor to 234 W and the 8-core POWER8 processor to 204 W.
  • Page 26 (feature code EKAJ or EKAZ): – If your 8001-22C system with feature code EKB1 or EKB5 has feature code EKAJ or EKAZ, and if the system has storage adapters (feature codes EKEA or EKEB), the system can support up to eight 3.5-inch drives.
  • Page 27 Figure 5. Removing a drive 3. If you are installing more than one drive, remove those drive trays. 4. For 3.5-inch drives, remove the plastic filler from the carrier. For 2.5-inch drives in a 3.5-inch opening, a 2.5-inch tool-less drive carrier exists. 5.
  • Page 28 When the pins are aligned, close the retention spring, allowing the pins to secure the drive in the tray. e. Turn the tray right side up. Figure 7. Turning the 2.5-inch tray upside-down Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 29 Figure 8. Mounting the 2.5-inch drive in the tray 6. Support the drive by the bottom as you position the drive, and insert it into the drive slot. Important: Ensure that the drive is fully seated and is all the way into the system. 7.
  • Page 30 You can also want to refer to: Adding a Storage Device or Path (https://access.redhat.com/ documentation/en-US/Red_Hat_Enterprise_Linux/7/html/Storage_Administration_Guide/ logical-unit-add-remove.html). 10. Load or restore data from your backup media. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 31: Installing A Drive On Module In The 8001-22C System

    Installing a drive on module in the 8001-22C system Learn how to install a drive on module (DOM) in the IBM Power System S822LC for Big Data (8001-22C) system. Before you begin Power off the system and place it in the service position. For instructions, see “Preparing the 8001-22C or 8005-22N system to remove and replace internal parts”...
  • Page 32 Figure 10. Installing a DOM 3. Prepare the system for operation. For instructions, see “Preparing the 8001-22C system for operation after you remove and replace internal parts” on page 94. 4. Configure the installed drive for your environment. After you insert the new drive, you need to rescan for the device.

  • Page 33: Installing A Graphics Processing Unit In The 8001-22C System

    Notes for thermal limitations: v If the 8001-22C system has no GPUs, the system can support up to twelve 3.5-inch drives. The ambient temperature must not be more than 35°C (95°F). If all twelve 3.5-inch drives are installed, the system limits the 10-core POWER8 processor to 234 W and the 8-core POWER8 processor to 204 W.
  • Page 34 Plug the GPU power cable (A) into the system backplane as shown in Figure 13 on page 19. Using your thumb, press the release latch on the connector to remove the cable. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 35 Figure 13. Plugging in the GPU power cable h. Insert the GPU and PCIe riser card into the chassis as shown in Figure 14 on page 20. 1) Retract the retaining pin (B) so the arrow points to the system. 2) Insert the riser, using the slots and alignment pins (A) to properly insert the riser.
  • Page 36 4. To install a GPU in position 5, remove the riser as shown in Figure 15. Figure 15. Removing the PCIe riser a. Retract the retaining pin (A) so the arrow is pointing to the system. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 37 b. Lift the PCIe riser from the system. c. Place the PCIe adapter riser on an ESD surface, with the PCIe adapter riser facing up. d. Remove the screws and the tail-stocks in positions 5 and 6. e. Plug the GPU (A) into the PCIe adapter riser (B) as shown in Figure 16. Figure 16.

  • Page 38: Installing Memory In The 8001-22C System

    94. Installing memory in the 8001-22C system Learn how to install memory in the IBM Power System S822LC for Big Data (8001-22C) system. Placement rules for memory in the 8001-12C or 8001-22C system Learn about the configurations and rules that apply to adding memory to the IBM Power System S821LC (8001-12C) or the IBM Power System S822LC for Big Data (8001-22C) system.

  • Page 39: Installing Memory In The 8001-22C System

    P2M1 C and D, P2M2 C and D Figure 19. Memory slot locations and plugging sequence Installing memory in the 8001-22C system Learn how to install memory in the IBM Power System S822LC for Big Data (8001-22C) system. Installing and configuring the system...
  • Page 40 Before you begin Power off the system and place it in the service position. For instructions, see “Preparing the 8001-22C or 8005-22N system to remove and replace internal parts” on page 92. Procedure 1. Attach the electrostatic discharge (ESD) wrist strap.
  • Page 41 b. Press firmly on each side of the memory DIMM until the locking tab locks in place with an audible click. Figure 21. Inserting the memory DIMM 6. If you removed the system processor air baffle, replace it. Insert the edge of the baffle into the fan support as shown in Figure 22 on page 26.

  • Page 42: Installing A Pcie Adapter In The 8001-22C System

    Figure 22. Installing the processor air baffle What to do next Prepare the system for operation. For instructions, see “Preparing the 8001-22C system for operation after you remove and replace internal parts” on page 94. Installing a PCIe adapter in the 8001-22C system Learn how to install Peripheral Component Interconnect Express (PCIe) adapters in the IBM Power System S822LC for Big Data (8001-22C).

  • Page 43: Pcie Adapter Placement Rules And Slot Priorities For The 8001-22C Or 8005-22N System

    8005-22N system Find information about the placement rules and slot priorities for the Peripheral Component Interconnect Express (PCIe) adapters that are supported for the IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N). PCIe slot descriptions The 8001-22C or 8005-22N system provides PCIe generation 3 slots.
  • Page 44 PCIe adapter placement rules Use this information to select slots for installing PCIe adapters in the 8001-22C or 8005-22N system. Table 7 provides information about the adapters, the slot priorities in the system they are supported on, and the maximum number of adapters that can be installed in the supported system. You can click the link that appears in the feature code column for more technical information specific to the PCIe adapter.
  • Page 45 Table 7. PCIe adapters supported in the 8001-22C or 8005-22N system (continued) Maximum number 8001-22C (Slot 8005-22N (Slot of adapters Feature code Description priority) priority) supported EKA3 Intel 82575EB dual-port 3, 4, 5, 7, 8 Gigabit Ethernet Controller PCIe x4.0 LP (Adapter FRU...
  • Page 46 Table 7. PCIe adapters supported in the 8001-22C or 8005-22N system (continued) Maximum number 8001-22C (Slot 8005-22N (Slot of adapters Feature code Description priority) priority) supported EKAM Mellanox MCX415A-CCAT 3, 5 ConnectX-4 EN 100 GbE Single-port QSFP28 PCIe3.0 x16 LP (Adapter FRU number:...
  • Page 47 Table 7. PCIe adapters supported in the 8001-22C or 8005-22N system (continued) Maximum number 8001-22C (Slot 8005-22N (Slot of adapters Feature code Description priority) priority) supported EKAU Mellanox MCX4121A-ACAT 3, 4, 5, 7, 8 ConnectX-4 Lx EN 25GbE dual-port SFP28 PCIe3.0 x8 LP...
  • Page 48 Table 7. PCIe adapters supported in the 8001-22C or 8005-22N system (continued) Maximum number 8001-22C (Slot 8005-22N (Slot of adapters Feature code Description priority) priority) supported EKEB SMC AOC-K-S3008L-L8i 12 3, 4, 5, 7, 8 Gbps SAS3/RAID 0,1 and 10 PCIe3.0 x8 LP with cables...

  • Page 49: Pcie Adapter Information By Feature Type For The 8001-22C Or 8005-22N

    PCIe adapter information by feature type for the 8001-22C or 8005-22N Find information about the Peripheral Component Interconnect Express (PCIe) adapters that are supported for the IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N). Installing and configuring the system...
  • Page 50 Broadcom (LSI) MegaRAID 9361-8i SAS3 Controller with 8 Internal Ports (1 GB Cache) PCIe3.0 x8 LP with cables (Adapter FRU number: AOC-K-9361-8IB-IB001) EKAB SMC AOC-K-S3008L-L8i 12 Gbps SAS3/RAID 0,1 and 10 PCIe3.0 x8 LP with cables (Adapter FRU number: AOC-K-S3008L-L8iB-IB001) Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 51: Gb/S Eight-Port Sas Internal Hba Adapter (Adapter Fru Number: Aoc-S3008L-L8E-P)

    Table 8. PCIe adapters supported in the 8001-22C or 8005-22N system (continued) Feature code Description EKED Broadcom (LSI) 9300-8E SAS3 HBA PCIe3.0 x8 LP Adapter (Adapter FRU number: AOC-SAS3-9300-8E) EKEG SMC quad-port NVMe Host Bus Adapter (PEX9733) PCIe3.0 x8 LP with cables (Adapter FRU...
  • Page 52 To check for operating system and partition requirements, see one of the following links: Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 53: Pcie3 X4 Intel X550 10Gbase-T Converged Network Adapter With Dual Rj45 Ports (Fc Eka0)

    IBM Prerequisite website (www-912.ibm.com/e_dir/eServerPrereq.nsf) v IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/ ssic/interoperability.wss) v The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website. (http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html) v For support details, see the Linux Alert website. (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html)

  • Page 54: Cavium (Qlogic) Bcm57840 4-Port Sfp+ 10 Gb Ethernet Adapter Pcie3.0 X8 Lp (Fc Eka1)

    – Ubuntu 14.04.5, or later – For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html). – The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website(http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html). – The latest version of enabling libraries and utilities may be downloaded from Fix Central(http://www.ibm.com/support/fixcentral/).
  • Page 55 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Installing and configuring the system...

  • Page 56: Intel 82599Es Ethernet Converged Network Adapter X520-Da2 Dual-Port 10G/1G Sfp+ Pcie2.0 X8 Lp (Fc Eka2)

    – Ubuntu 14.04.5, or later – For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html). – The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website(http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html). – The latest version of enabling libraries and utilities may be downloaded from Fix Central(http://www.ibm.com/support/fixcentral/).
  • Page 57 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Preboot eXecution Environment (PXE) support...

  • Page 58: Intel 82575Eb Dual-Port Gigabit Ethernet Controller Pcie X4.0 Lp (Fc Eka3)

    PCIe 10/100/1000 Ethernet connection. It also improves flexibility and performance in a virtualized environment in multi-core systems by lowering interrupt overhead and providing sorted multiple data queue paths. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 59 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Preboot eXecution Environment (PXE) support...

  • Page 60: Broadcom (Lsi) Megaraid 9361-8I Sas3 Controller With 8 Internal Ports (1 Gb Cache) Pcie3.0 X8 Lp With Cables (Fc Ekaa And Ekea)

    – Ubuntu 14.04.5, or later – For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html). – The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website(http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html). – The latest version of enabling libraries and utilities may be downloaded from Fix Central(http://www.ibm.com/support/fixcentral/).
  • Page 61 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Port independent auto-negotiation Automatically negotiates PCIe link widths Supports 1.5, 3.0, 6.0 and 12 Gb/s SAS and SATA data transfer rates...

  • Page 62: Smc Aoc-K-S3008L-L8I 12 Gbps Sas3/Raid 0,1 And 10 Pcie3.0 X8 Lp With Cables (Fc Ekab And Ekeb)

    – Ubuntu 14.04.5, or later – For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html). – The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website(http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html). – The latest version of enabling libraries and utilities may be downloaded from Fix Central(http://www.ibm.com/support/fixcentral/).
  • Page 63 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Port independent auto-negotiation Supports MegaRAID Storage Manager software Supports 3.0, 6.0 and 12 Gb/s SAS and SATA data transfer rates...

  • Page 64: Broadcom (Lsi) 9300-8E Sas3 Hba Pcie3.0 X8 Lp Adapter (Fc Ekad And Eked)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 65 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Port independent auto-negotiation...

  • Page 66: Pcie3 X8 Dual-Port Internal Nvme Host Bus Adapter (Fc Ekae And Ekee)

    – Ubuntu 14.04.5, or later – For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html). – The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website(http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html). – The latest version of enabling libraries and utilities may be downloaded from Fix Central(http://www.ibm.com/support/fixcentral/).
  • Page 67 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Four internal lanes per port and 32 Gb/s per port (PCIe3 speed)

  • Page 68: Emulex Lpe16002B-M6-O Dual-Port 16 Gb Fibre Channel Card Pcie3.0 X8 Lp (Fc Ekaf)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 69 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Auto-negotiation LDAP support Data transfer rate of 14.025 Gb/s...

  • Page 70: Smc Quad-Port Nvme Host Bus Adapter (Pex9733) Pcie3.0 X8 Lp With Cables (Fc Ekag And Ekeg)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 71 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Supports four physical NVMe devices...

  • Page 72: Broadcom (Lsi) Megaraid 9361-8I Sas3

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 73 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Port independent auto-negotiation...

  • Page 74: Nvidia Tesla K80 24 Gb Gpu Accelerator (Fc Ekaj)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 75 Form factor Double-wide, full-height Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes Dynamic Parallelism Error Correcting Codes (ECC) Memory...

  • Page 76: Mellanox Mcx456A-Ecat Connectx-4 Vpi Edr Ib 100 Gb/S And 100 Gbe Dual-Port Qsfp28 Pcie3.0 X16 Lp (Fc Ekal)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 77 Short, with full-height tailstock Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided EDR 100 Gb/s InfiniBand or 100 Gb/s Ethernet per port...
  • Page 78 – Ubuntu 14.04.5, or later – For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html). – The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website(http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html). – The latest version of enabling libraries and utilities may be downloaded from Fix Central(http://www.ibm.com/support/fixcentral/).

  • Page 79: Mellanox Mcx415A-Ccat Connectx-4 En 100 Gbe Single-Port Qsfp28 Pcie3.0 X16 Lp (Fc Ekam)

    Short, with full-height tailstock Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided 100 Gb/s Ethernet per port...

  • Page 80: Qlogic Qle2562 Dual-Port 8 Gb Fibre Channel Adapter Pcie X8 Lp (Fc Ekap)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 81 Form factor Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided StarPower technology Auto-negotiation...

  • Page 82: Qlogic Qle2692Op Dual-Port 16 Gb Fibre Channel Adapter Pcie3 X8 Lp (Fc Ekaq)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 83 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Up to 1.3 million IOPS fuel high performance in AFAs and high density virtualized environments...

  • Page 84: Alpha-Data Capi Adapter: Adm-Pcie Ku3 (Fc Ekat)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 85 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Dual QSFP cages for high-speed optical communication including 10 and 40 Gigabit Ethernet...
  • Page 86 To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...

  • Page 87: Mellanox Mcx4121A-Acat Connectx-4 Lx En 25Gbe Dual-Port Sfp28 Pcie3.0 X8 Lp (Fc Ekau)

    Short, with full-height tailstock Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided Low latency RDMA over Converged Ethernet...

  • Page 88: Nvidia Tesla P100 16Gb Pcie3.0 X16 Dual-Slot Fhfl With Cables (Fc Ekaz)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme. (https://ibm.biz/BdrgTZ) v Linux –...
  • Page 89 3.3 V, 12 V Form factor Double-wide, full-height Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes Pascal Architecture NVLink...

  • Page 90: Intel Xl710 Ethernet Converged Network Adapter Quad-Port 10G/1G Sfp+ Pcie3.0 X8 Lp (Fc Ekfh)

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 91 AOC-STG-I4S (Designed to comply with RoHS requirement) I/O bus architecture PCIe x8 Slot requirement For details about slot priorities and placement rules, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/p8eab/ p8eab_mtm_pciplacement.htm) and select the system you are working on. Supported Systems POWER8 processor-based systems Voltage 3.3 V, 12 V...

  • Page 92: Pcie3 1.6 Tb Nvme Flash Adapter (Fc Ekn2)

    IBM Prerequisite website (www-912.ibm.com/e_dir/eServerPrereq.nsf) v IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/ ssic/interoperability.wss) v The latest version of the device driver or iprutils can be downloaded from the IBM Service and Productivity Tools website. (http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/ home.html) v For support details, see the Linux Alert website. (www14.software.ibm.com/webapp/set2/sas/f/ lopdiags/info/LinuxAlerts.html)
  • Page 93 Short, low-profile Maximum number For details about the maximum number of adapters that are supported, see PCIe adapter placement rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER8/ p8eab/p8eab_mtm_pciplacement.htm) and select the system you are working on. Attributes provided 1.6 TB of low latency flash memory...

  • Page 94: Installing A Pcie Adapter In The 8001-22C System

    To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/ eServerPrereq.nsf). The adapter is supported on the following versions of the operating systems: Important: For a list of known Linux OS issues that may affect this adapter, see the IBM Power LC readme (https://ibm.biz/BdrgTZ). v Linux –...
  • Page 95 Before you begin Power off the system and place it in the service position. For instructions, see “Preparing the 8001-22C or 8005-22N system to remove and replace internal parts” on page 92. Procedure 1. Attach the electrostatic discharge (ESD) wrist strap.
  • Page 96 Remove the screw and the tail-stock filler for that position. e. If you are inserting a storage drive adapter, connect the signal cables to the adapter before inserting the adapter. See “Drive installation information for the 8001-22C system” on page 7 for cabling information.
  • Page 97 Figure 48. Inserting an adapter into position 3 of the PCIe riser g. Replace the screw to secure the tail-stock. h. If you have a SAS super capacitor carrier, insert that carrier (A) in position 2 of the PCIe adapter riser (B) as shown in Figure 49.
  • Page 98 4. To install an adapter in position 4, complete the following steps: a. Retract the retaining pin and slide the retaining door open to release the tail-stock as shown in Figure 51 on page 83. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 99 Remove the tail-stock filler. c. If you are inserting a storage drive adapter, connect the signal cables to the adapter before inserting the adapter. See “Drive installation information for the 8001-22C system” on page 7 for cabling information. NVMe drives are only supported on host operating systems; NVMe drives are not supported by guest operating systems.
  • Page 100 5. To install an adapter in position 5, 6, 7, and 8, remove the riser as shown in Figure 53. Figure 53. Removing the PCIe riser a. Retract the retaining pin (A) so the arrow is pointing to the system. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 101 Remove the screw and the tail-stock filler for that position. f. If you are inserting a storage drive adapter, connect the signal cables to the adapter before inserting the adapter. See “Drive installation information for the 8001-22C system” on page 7 for cabling information.
  • Page 102 2) Insert the riser, using the slots and alignment pins (A) to properly insert the riser. Push the riser firmly into the system backplane. 3) Set the retaining pin (B) to secure the riser. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 103: Common Procedures For Servicing Or Installing Features In The 8001-22C Or 8005-22N

    Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v If IBM supplied the power cord(s), connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.
  • Page 104 To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet. Always install servers and optional devices starting from the bottom of the rack cabinet. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 105 Procedure 1. If you are installing a new feature, ensure that you have the software that is required to support the new feature. See IBM Prerequisite. Installing and configuring the system...

  • Page 106: Identifying The System That Contains The Part To Replace

    Learn how to determine which system has the part you want to replace. LEDs on the 8001-22C or 8005-22N system Use this information as a guide to the LEDs on the IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system.
  • Page 107 Figure 58. LEDs on the front of the system LEDs are also on the rear of the system; see Figure 59. The identify LED is at (2). Turn it on by using a system identify command. Figure 59. LEDs on the rear of the system Drive LEDs can indicate the following states: v Blue activity LED can indicate the following states: –...

  • Page 108: Identifying The 8001-12C, 8001-22C, 8005-12N, Or 8005-22N That Needs Servicing

    -I lanplus -H <hostname> -U <username> -P <password> chassis identify <interval> Preparing the 8001-22C or 8005-22N system to remove and replace internal parts Learn how to prepare the IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system to remove and replace internal parts. Procedure 1.
  • Page 109 Note: The system might be equipped with redundant power supply. Before you continue with this procedure, ensure that all power to your system is disconnected. (L003) Installing and configuring the system...

  • Page 110: Preparing The 8001-22C System For Operation After You Remove And Replace Internal Parts

    Preparing the 8001-22C system for operation after you remove and replace internal parts Learn how to prepare the IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system for operation after you remove and replace internal parts.

  • Page 111: Starting And Stopping The 8001-12C, 8001-22C, 8005-12N, Or 8005-22N

    Starting and stopping the 8001-12C, 8001-22C, 8005-12N, or 8005-22N Learn how to start and stop the IBM Power System S821LC (8001-12C), the IBM Power System S822LC for Big Data (8001-22C), the IBM CS821 (8005-12N), or the IBM CS822 (8005-22N) system to perform a service action or system upgrade.
  • Page 112 Figure 61. Power switch for 8001-22C What to do next If you press the power button and the system does not start, contact your next level of support or your service provider. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 113: Stopping The 8001-12C, 8001-22C, 8005-12N, Or 8005-22N System

    Stopping the 8001-12C, 8001-22C, 8005-12N, or 8005-22N system Learn how to stop the IBM Power System S821LC (8001-12C), the IBM Power System S822LC for Big Data (8001-22C), the IBM CS821 (8005-12N), or the IBM CS822 (8005-22N) systems to complete another task.

  • Page 114: Storcli Commands

    To turn off the identify LED: storcli /cx[/ex]/sx stop locate To prepare a drive for removal: storcli /cx[/ex]/sx spindown To prepare a drive for use: storcli /cx[/ex]/sx spinup Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)

  • Page 115: Sas3Ircu Commands

    sas3ircu commands Learn about the sas3ircu command. This command is for feature code EKAB using a PCIe adapter. If the sas3ircu command is not installed, download the utility from ftp://ftp.supermicro.com/driver/ P8DTU/. You can find the download by searching that site for sas3ircu; currently: LSI MegaRAID and HBA (AOC-Utility) >...

  • Page 116: Sensor Readings Gui Display

    Removing and replacing a power supply in the 8001-12C, 8001-22C, 8005-12N, or 8005-22N Learn how to remove and replace power supplies in the IBM Power System S821LC (8001-12C), the IBM Power System S822LC for Big Data (8001-22C), the IBM CS821 (8005-12N), or the IBM CS822 (8005-22N) systems.
  • Page 117 5 seconds. 2. Label and remove the power cord from the power supply to remove. For instructions, see “Disconnecting the power cords from an 8001-12C, 8001-22C, 8005-12N, or 8005-22N system” on page 107. 3. Remove the power supply from the system.

  • Page 118: Replacing A Power Supply In The 8001-12C, 8001-22C, 8005-12N, Or 8005-22N

    Removing and replacing covers on an 8001-22C or 8005-22N system Learn how to remove and replace the covers for an IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system so that you can access the hardware parts or service the system.

  • Page 119: Installing The Service Access Cover On An 8001-22C Or 8005-22N System

    4. Lift up the front of the cover up and remove it from the system. Installing the service access cover on an 8001-22C or 8005-22N system Learn how to install the service access cover on a rack-mounted IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system.

  • Page 120: Service And Operating Positions For 8001-22C Or 8005-22N

    3. Replace the two cover screws, one on each side of the cover. Service and operating positions for 8001-22C or 8005-22N Learn how to place an IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system into the service or operating position.
  • Page 121 does not slide out of the system. If the drive does not match the serial number you wrote down in the previous step, reinstall the drive in the bay you removed it from, and check the other drive bays. Figure 66. Removing a drive 3.

  • Page 122: Placing An 8001-22C Or 8005-22N System Into The Operating Position

    7. Carefully set the system on a table with an appropriate ESD surface. Placing an 8001-22C or 8005-22N system into the operating position Learn how to place an IBM Power System S822LC for Big Data (8001-22C) or the IBM CS822 (8005-22N) system into the operating position.

  • Page 123: Power Cords

    8. Replace the power supplies. Power cords Learn how to disconnect and connect the power cords on IBM Power System S821LC (8001-12C), the IBM Power System S822LC for Big Data (8001-22C), the IBM CS821 (8005-12N), or the IBM CS822 (8005-22N) systems.

  • Page 124: Connecting The Power Cords To An 8001-12C, 8001-22C, 8005-12N, Or 8005-22N System

    Connecting the power cords to an 8001-12C, 8001-22C, 8005-12N, or 8005-22N system Learn how to connect the power cords to an IBM Power System S821LC (8001-12C), the IBM Power System S822LC for Big Data (8001-22C), the IBM CS821 (8005-12N), or the IBM CS822 (8005-22N) system.

  • Page 125: Notices

    Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.

  • Page 126: Accessibility Features For Ibm Power Systems Servers

    All IBM prices shown are IBM's suggested retail prices, are current and are subject to change without notice. Dealer prices may vary. This information is for planning purposes only. The information herein is subject to change before the products described become available.

  • Page 127: Privacy Policy Considerations

    This product uses standard navigation keys. Interface information The IBM Power Systems servers user interfaces do not have content that flashes 2 - 55 times per second. The IBM Power Systems servers web user interface relies on cascading style sheets to render content properly and to provide a usable experience.

  • Page 128: Trademarks

    IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the web at Copyright and trademark information at www.ibm.com/legal/copytrade.shtml.
  • Page 129 European Community contact: IBM Deutschland GmbH Technical Regulations, Abteilung M456 IBM-Allee 1, 71139 Ehningen, Germany Tel: +49 800 225 5426 email: halloibm@de.ibm.com Warning: This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
  • Page 130 Electromagnetic Interference (EMI) Statement - Taiwan The following is a summary of the EMI Taiwan statement above. Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 131 Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.

  • Page 132: Class B Notices

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Proper cables and connectors are available from IBM-authorized dealers. IBM is not responsible for any radio or television interference caused by unauthorized changes or modifications to this equipment.
  • Page 133 This product is in conformity with the protection requirements of EU Council Directive 2014/30/EU on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-IBM option cards.
  • Page 134 Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.

  • Page 135: Terms And Conditions

    Permissions for the use of these publications are granted subject to the following terms and conditions. Applicability: These terms and conditions are in addition to any terms of use for the IBM website. Personal Use: You may reproduce these publications for your personal, noncommercial use provided that all proprietary notices are preserved.
  • Page 136 Power Systems: Installing the IBM Power System S822LC for Big Data (8001-22C)
  • Page 138 IBM® Printed in USA...

This manual is also suitable for:

S822lc

Table of Contents
