Figure 5. Drive on module (DOM) locations
The following table provides the drive on module (DOM) locations.
Table 32. Drive on module (DOM) locations
Index number
41
42
8001-12C or 8005-12N parts
Use this information to find the field-replaceable unit (FRU) part number.
After you identify the part number of the part that you want to order, go to Advanced Part Exchange
Warranty Service. Registration is required. If you are not able to identify the part number, go to
Contacting IBM service and support.
78
Problem analysis, system parts, and locations for the 8001-12C, 8001-22C, 8005-12N, and 8005-22N
FRU description
Drive on module (DOM) 0
Drive on module (DOM) 1
FRU removal and replacement
procedures
See Removing and replacing a
storage drive in the 8001-12C or
8005-12N.
See Removing and replacing a
storage drive in the 8001-12C or
8005-12N.
