Table 34. System parts (continued)
Index
number Part number
10 HDS-KIT-3N-1200-
IB001
10 HDS-KIT-3N-1600-
IB001
10 HDS-KIT-3N-2000-
IB001
10 HDS-KIT-5N-800-
IB001
10 HDS-KIT-5N-3200-
IB001
10 HDS-KIT-2T-480-
IB001
10 HDS-KIT-2T-960S-
IB001
10 HDS-KIT-2T-1920-
IB001
11 BPN-SAS3-815TQ-
N4
12
13 FAN-0141L4
14
15 MCP-310-81909-0B
16 MCP-310-81908-0B
82
Problem analysis, system parts, and locations for the 8001-12C, 8001-22C, 8005-12N, and 8005-22N
Units per assembly Description
4 1.2 TB small form factor NVMe drive (3 drive writes per
day) (8001-12C)
4 1.6 TB small form factor NVMe drive (3 drive writes per
day) (8001-12C)
4 2.0 TB small form factor NVMe drive (3 drive writes per
day) (8001-12C)
4 800 GB small form factor NVMe drive (5 drive writes per
day) (8001-12C)
4 3.2 TB small form factor NVMe drive (5 drive writes per
day) (8001-12C)
4 480 GB 2.5 inch SATA solid-state drive (3.5 drive writes per
day) (8005-12N)
4 960 GB 2.5 inch SATA solid-state drive (3.5 drive writes per
day) (8005-12N)
4 1.92 TB 2.5 inch SATA solid-state drive (3.5 drive writes per
day) (8005-12N)
1 Disk drive backplane
2 Screws
8 Fan
2 Fan holder
1 CPU 1 air baffle
1 CPU 2 air baffle
