Hardware Documentation Updates
TABLE 6
Title
Sun SPARC Enterprise
M4000/M5000 Servers Site
Planning Guide
Sun SPARC Enterprise
M4000/M5000 Servers
Service Manual
Sun SPARC Enterprise
M4000/M5000 Servers
Installation Manual
Sun SPARC Enterprise
M8000/M9000 Servers
Overview Guide
16 Sun SPARC Enterprise M4000/M5000 Servers Product Notes for XCP Version 1060 • November 2007
Page Number Update
Updated glossary terms:
External I/O Expansion Unit — A rackmountable device to add
on PCI slots. It is connected to the system's I/O unit through
the PCIe connection and contains one or two I/O boats.
I/O boat — An I/O unit in the External I/O Expansion Unit.
The I/O boat connects to a PCI-Express (PCIe) slot through a
PCIe switch or a PCI-X bridge on the I/O boat and offers either
six PCI-X slots or six PCIe slots.
1-7 TABLE 1-3 "Midrange Servers Physical Specifications"
Correct numerical value of "Depth" is 810mm/31.9 in. for the
Sun SPARC Enterprise M4000/M5000 servers.
2-4 TABLE 2-2 "Midrange Servers Electrical Specifications"
See "Electrical Specifications" on page 15
for the changes.
8-6 8.1.3, "Installing the PCI Cassette"
See "Installing the PCI Cassette" on page 5
Notes for the changes.
11-7 11.2, "DIMM Replacement"
See "DIMM Replacement" on page 5
the changes.
C-7 TABLE C-5 "Power Supply Feature"
See "Electrical Specifications" on page 15
for the changes.
8-3 3.3, "Connecting the Administration Console".
The RJ-11 connector at the top of Figure 3-1 was not labelled.
The RJ-11 connector is not for connection to TNV circuits. Do
not use this connector.
Page 1-8 In Table 1-1, "Main Unit Specification"
The following information will be added.
Architecture: SPARCV9 architecture
Platform groups: sun4u
Platform names: SunW, SPARC-Enterprise
in these Product Notes
in these Product
in these Product Notes for
in these Product Notes
