Note – The numbering in a Sun Rack reads from bottom to top and right to left.
Wiring Connections for Three Sun SPARC Enterprise M5000 Servers with One
TABLE 4
60A 3-phase MPS
Server M5000 PSU_3
M5000_2 MPS_0-B5
M5000_1 MPS_0-B3
M5000_0 MPS_0-B1
Wiring Connections for Three Sun SPARC Enterprise M5000 Servers with Two
TABLE 5
30A 3-phase MPS
Server M5000 PSU_3
M5000_2 MPS_1-B2
M5000_1 MPS_1-B1
M5000_0 MPS_1-B0
M5000 PSU_2
MPS_0-A5
MPS_0-A3
MPS_0-A1
M5000 PSU_2
MPS_1-A2
MPS_1-A1
MPS_1-A0
Sun SPARC Enterprise M4000/M5000 Servers Product Notes
M5000 PSU_1 M5000 PSU_0
MPS_0-B4 MPS_0-A4
MPS_0-B2 MPS_0-A2
MPS_0-B0 MPS_0-A0
M5000 PSU_1 M5000 PSU_0
MPS_0-B2 MPS_0-A2
MPS_0-B1 MPS_0-A1
MPS_0-B0 MPS_0-A0
