Power Wiring Configurations

The following information belongs in the Sun SPARC Enterprise Equipment Rack
Mounting Guide.
To ensure redundant power sourcing, use the provided wiring configurations for the
Sun SPARC Enterprise M4000/M5000 servers in a Sun Rack 1000 38/42.
The Sun Rack 1000-38/42 can fit up to two modular power supplies (MPS). Each
MPS is two rack units tall. The MPS must be installed into the bottom of the rack.
Note – The numbering in a Sun Rack reads from bottom to top and right to left.
Wiring Connections for Six Sun SPARC Enterprise M4000 Servers with One
TABLE 2
60A 3-phase MPS
Server
M4000_5
M4000_4
M4000_3
M4000_2
M4000_1
M4000_0
Wiring Connections for Six Sun SPARC Enterprise M4000 Servers with Two
TABLE 3
30A 3-phase MPS
Server
M4000_5
M4000_4
M4000_3
M4000_2
M4000_1
M4000_0
M4000 PSU_1
MPS_0-A5
MPS_0-A4
MPS_0-A3
MPS_0-A2
MPS_0-A1
MPS_0-A0
M4000 PSU_1
MPS_1-B5
MPS_0-B4
MPS_1-B3
MPS_0-B2
MPS_1-B1
MPS_0-B0
Sun SPARC Enterprise M4000/M5000 Servers Product Notes
M4000 PSU_0
MPS_0-B5
MPS_0-B4
MPS_0-B3
MPS_0-B2
MPS_0-B1
MPS_0-B0
M4000 PSU_0
MPS_1-A5
MPS_0-A4
MPS_1-A3
MPS_0-A2
MPS_1-A1
MPS_0-A0
