10. Edit time in step 2 and press [Enter] key.
EDIT LIST
Step 02 Width=5.00S
11. Edit repeat count and press [Enter] key.
EDIT LIST
Repeat Count=3
12. Save all edited files and press [Enter] key.
EDIT LIST
Save List File=1 (1-7)
13. Operate
that indicates VFD screen status is on). Press [Esc] key to exit setting.
LIST
On Recall Edit
14. Press [On/Off] key to open input and press [Shift] + .(Trigger) key
(Triggering key).
List operation running
15. Press [CC]/ [CV]/ [CR]/ [CW] key or any composite function key to exit List
test function.
For direct recall of existing List files and triggering of List operation, refer to
steps below:
Operation steps
1. Press [Shift] +3 (List) keys. Press
press [Enter] for confirmation.
LIST
On Recall Edit
2. Select edited files and press [Enter] for confirmation.
Recall List File=1
3. Operate
that indicates VFD screen status is on). Press [Esc] key to exit setting.
LIST
On Recall Edit
4. Press [On/Off] key to open input and press [Shift] + .(Trigger) key
(Triggering key)
List operation.

3.18 Terminal function of rear panel

Terminals on IT8300 rear panel comprise remote sensor terminal, external
analog control terminal and current monitoring terminal. Terminal schematic (as
shown below):
key and move to on. Press [Enter] key (The Trig lamp
key and move to on. Press [Enter] key (The Trig lamp
