1 Introduction

1.1 Purpose of the Manual

This instruction manual provides information for safe
installation and commissioning of the adjustable frequency
drive.
This instruction manual is intended for use by qualified
personnel.
Read and follow the instruction manual to use the
adjustable frequency drive safely and professionally, and
pay particular attention to the safety instructions and
general warnings. Keep this instruction manual available
with the adjustable frequency drive at all times.

1.2 Additional Resources

Other resources are available to understand advanced
adjustable frequency drive functions and programming.
•
The VLT
detail on working with parameters and many
application examples.
•
The VLT
information about capabilities and functionality to
design motor control systems.
•
Instructions for operation with optional
equipment.
Supplementary publications and manuals are available
from Danfoss. See www.danfoss.com/BusinessAreas/DrivesSo-
lutions/Documentations/VLT+Technical+Documentation.htm
for listings.
Disclosure, duplication and sale of this document, as well
as communication of its content, are prohibited unless
explicitly permitted. Infringement of this prohibition incurs
liability for damages. All rights reserved with regard to
patents, utility patents and registered designs. VLT
registered trademark.

1.3 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition
MG20MAxx
Table 1.1 Document and Software Version
4
VLT
®
Programming Guide provides greater
®
Design Guide provides detailed
Remarks Software version
Replaces MG20M9xx
Danfoss A/S © 10/2014 All rights reserved.
®
AQUA Drive FC 202

1.4 Product Overview

1.4.1 Intended Use
The adjustable frequency drive is an electronic motor
controller intended for
•
regulation of motor speed in response to system
feedback or to remote commands from external
controllers. A power drive system consists of the
adjustable frequency drive, the motor, and
equipment driven by the motor.
•
system and motor status surveillance.
Depending on configuration, the adjustable frequency
drive can be used in standalone applications or form part
of a larger appliance or installation.
The adjustable frequency drive is allowed for use in
residential, industrial and commercial environments in
accordance with local laws and standards.
Single phase adjustable frequency drives (S2 and S4)
installed in the EU
The following limitations apply:
Units with an input current below 16 A and an input
power above 1 kW are only intended for professional use
in trades, professions, or industries and not for sale to the
general public. Designated application areas are public
pools, public water supplies, agriculture, commercial
buildings, and industries. All other single phase units are
only intended for use in private low-voltage systems
interfacing with public supply only at a medium or high
voltage level. Operators of private systems must ensure
that the EMC environment complies with IEC 610000-3-6
and/or the contractual agreements.
NOTICE!
®
is a
In a residential environment, this product can cause
radio interference, in which case supplementary
mitigation measures can be required.
2.xx
