Danfoss VLT AQUA Drive FC 202 Instruction Manual page 71

Specifications
525–600 V
Enclosure Power [kW]
A2 1.5–5 [1.1–4.0]
A3 7.5–10 [5.5–7.5]
A5 1.5–10 [1.1–7.5]
B1 15–25 [11–18]
B2 30–40 [22–30]
B3 15–25 [11–18.5]
B4 30–50 [22–37]
C1 50–75 [37–55]
C2 100–125 [75–90]
C3 60–75 [45–55]
C4 100–125 [75–90]
Table 8.15 525–600 V, Enclosure Types A, B and C
MG20MA22
Instruction Manual
Recommended
fuse size
gG-10
gG-10 (7.5 [5.5])
gG-16 (10 [7.5])
gG-10 (1–7.5 [0.75–5.5])
gG-16 (10 [7.5])
gG-25 (15 [11])
gG-32 (20 [15])
gG-40 (25 [18.5])
gG-50 (30 [22])
gG-63 (40 [30])
gG-25 (15 [11])
gG-32 (20 [15])
gG-40 (25 [18.5])
gG-50 (30 [22])
gG-63 (40 [30])
gG-63 (50 [37]) gG-160 (50–60 [37–45])
gG-100 (60 [45])
aR-160 (75 [55])
aR-200 (100 [75])
gG-63 (50 [37])
gG-100 (60 [45])
aR-160 (75 [55])
aR-200 (100 [75])
Danfoss A/S © 10/2014 All rights reserved.
Recommended Recommended circuit
max. fuse breaker
Moeller
gG-25 PKZM0-25
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
gG-63 PKZM4-50
gG-125 NZMB1-A100
NZMB2-A200
aR-250 (75 [55])
aR-250 NZMB2-A250
gG-150 NZMB2-A200
aR-250 NZMB2-A250
Max. trip level [A]
25
25
25
63
100
50
100
8
160
250
150
250
69
8
