SMA SUNNY SENSORBOX Installation Manual page 57

SMA Solar Technology AG
Mounting location
Applicability
Connections
Connections
Max. range
RS485-Power Injector to the last Sunny
SensorBox
Power supply
Power supply via
Power consumption
Environmental conditions during operation
Ambient temperature
Relative humidity
Warranty, Certificates and Permits
Warranty
Certificates and permits
Plug-in power supply
General data
Dimensions (W/H/D) in inches
Weight
Mounting location
Power supply
Input voltage
Output voltage
Output current
Warranty
Warranty
Module Temperature Sensor
General data
Sensor resistor
Mounting location
Connection cable
Connection cable (for 2-conductor technology)
Measured values
Accuracy
Installation Guide
indoors
Wall mounting, tabletop device
Connection for the plug-in power supply, RS485
IN, RS485 + Power OUT
492 ft.
Plug-in power supply
< 5 W in case of 5 Sunny SensorBox devices
-4 °F to +149 °F
5 % to 95 %, non-condensing
5 years
www.SMA-America.com
4.24/2.27/1.32
10.58 oz
indoors
100 V - 240 V AC, 50 / 60 Hz
12 V DC ± 2 %
max. 2.5 A
5 years
PT100
outdoors
Pre-configured cable length of 8.2 ft.
± 0.9 °F
Sensorbox-IUS084413
Technical Data
57
