11 Channel List
The channel list is divided up into values and parameters. Values, such as the serial number (SN) for
example, are read-only. You can make parameter settings, such as changing the temperature unit
(TmpUnit).
11.1 General Parameters
Channel
SN Here, the serial number of the Sunny SensorBox is displayed.
FwVer Here, the firmware version of the Sunny SensorBox is displayed.
HwVer Here, the hardware version of the Sunny SensorBox is
displayed.
SMA-h-On Here, the number of operating hours the Sunny SensorBox has
been operating since its commissioning is displayed.
TmpUnit This allows you to select the unit in which the temperature is to
be displayed. You can select one of the following units:
• °C (factory setting)
• K
• °F
WindUnit This allows you to select the unit in which the wind speed is to be
displayed. You can select one of the following units:
• m/s (factory setting)
• km/h
• mph
DevRs Using this channel, you can reset the Sunny SensorBox. The
value of this channel is always "0". If you wish to reset the Sunny
SensorBox, enter the value "1", and save it. The Sunny
SensorBox then resets, but the alteration to the channel's setting
is not applied. The LED in the Sunny SensorBox then remains off
for 60 seconds.
RS485DI Response delay of the Sunny SensorBox to the RS485 bus. This
channel must be set to "200ms" if you are using a Sunny Boy
Control/ Plus or Sunny Central Control as communication
device. Factory setting is 200 ms. When operating the Sunny
SensorBox with a Sunny WebBox, the response delay can be
reduced to 10ms. This channel is only visible if you are logged
in at the communication device as "installer". Refer to your
communication device's user manual.
Installation Guide
Explanation Value Parameter
x
x
x
x
Sensorbox-IUS084413

Channel List

x
x
x
x
