SMA Solar Technology AG

11.5 External Irradiation Sensors

An external irradiation sensor is currently not supported.

Channel

ExtSolIrr

Here, the current solar irradiation level is displayed in W/m².

ExtSolIrrCal

Here, you must set the voltage of the connected irradiation

sensor in mV. Factory setting is "100mV".

ExtSolIrrFnc

Here, you must set the input range of the connected irradiation

sensor. Factory setting is 0 mV to 300 mV.

11.6 Anemometer

If no anemometer is present, the value "0" is displayed in these channels.

Channel

WindVel m/s Current wind speed in the selected unit.

WindVel km/

• m/s

• km/h

WindVel mph

• mph

The only channel ever visible is that of the selected unit. You can

set the required unit using the general WindUnit channel.

Installation Guide

Explanation

Value Parameter

Sensorbox-IUS084413

Channel List
