Explanation Of Symbols - SORG Loop RS Service Record

2 General information

2.4 Explanation of symbols

ATTENTION! Warnings for perso-
nal Safety aspects that are of the
utmost importance.
CORRECT safety adjustment/ use
WRONG adjustment/ use
NOT ALLOWED
References to additional/conti-
nuing reading.
Use
push/ pull/ insert / move/
Push in specific direction
Setting or adjusting the angle
open/ close
Turn clockwise
Turn counter-clockwise
steps to be done at the same
1. 1.
time
1. 2.
;
steps to be done after each other
2x
steps to be done on both sides
2019-07-16
( A ) ; ( B )
Service Record Loop
SORG
important detail
correct or proper use/setting
incorrect or improper use/setting
reference from text to detail
point of view
view from top
view from the side
view from the bottom
view from the front
view from the back
fasten parts
remove parts
RS 7 of 40
