2 General information

2.2.1 Explanation of symbols

ATTENTION! Warnings for per-
sonal safety issues, of utmost
importance
CORRECT safety-relevant set-
ting/ handling
WRONG setting/ handling
PROHIBITED
Reference to additional / further
reading.
Handling
Push / pull / insert / move / re-
move
Push in a certain direction
Set or adjust the angle
Open / close
Turn clockwise
Turn counter clockwise
Steps to be performed at the
1. 1.
same time
Steps to be performed in se-
1. 2.
quence
;
Steps to be performed on both
2x 2x
sides
6 von 40
( A ) ; ( B )
Instructions for use Dynamis MV
Important detail / element
Correct or proper setting / use
Inadmissible or incorrect setting
/ use
Reference from text to detail
Perspective
View from above
Side view
View from below
Front view
Rear view
Attach part
Remove part
