EKKO EK20R Manual page 21

1. Brake baseplate assembly
assembly
6.Return Spring
9. .Return Spring
12. Adjustment Lever
15.Pressure spring Cover
spring seat
20.Washer
cable assembly
25.Brake cylinder
pump piston top rod
30.Brake pump spring
Bleed screw 33.screw protector for pump vent
5.3.5 Parking brake operating device
The parking brake handle is cam type. And the brake can be adjusted by the
adjuster at the end of the brake handle.
Braking force adjustment :turn the adjuster clockwise to increase the
braking force ,turn the adjuster counterclockwise to reduce the braking force,
pulling force:200 N~300N
2. Slack adjuster
4. Elastic gasket wire
7. Washer
10. Hand push Rod
13.Pressure spring seat
18.Pressure spring Lever
21.Rubber plug
23.Bolt M8×16
26.Brake pump guard
28.Piston
31.Brake oil plug
3. Friction disc
5. Hand brake lever
8.Pole
11. Compressed spring
16.Spring
19.Support pin
24.Spring Washer 8
29.Cylinder Cup
34.Dust cover
15
aring brake handle
14. Spring
17.Pressure
22.Brake
27.Brake
32.Brake cylinder
P
