DataView™ LI55 Level Controller
We Do Your Level Best
Thank you for purchasing the Dataview™ Analog Input Display (LI55).
The LI55 Series is a multipurpose, easy to use digital process meter
ideal for level applications. It accepts current signals (4-20 mA) and has
four front panel buttons for configuration of the display.
A fully loaded LI55 Series meter has the following: four SPDT relays,
4-20 mA output, and two 24 VDC power supplies. The four relays can
be used for alarm indication or process control applications, such as
pump alternation control. The 4-20 mA isolated output, and digital I/O
options make the LI55 Series an excellent addition to any system.

Ordering Information

Standard Models
85-265 VAC
Model
LI55-1001
LI55-1201
LI55-1011
LI55-1401
LI55-1211
LI55-1411
*Model number for replacement option card.
Accessories
Model
LI56-1400
LI56-1000
LM91-1001
LM91-2001
12/24 VDC
Model
LI55-8001
LI55-8201
LI55-8011
LI55-8401
LI55-8211
LI55-8411
Description
4 SPST (Form A) relays
Meter copy cable
Single Display NEMA 4X Enclosure
Dual Display NEMA 4X Enclosure
Options Installed
No options
2 relays (LI56-1201*)
4-20 mA output (LI56-1011*)
4 relays (LI56-1401*)
2 relays & 4-20 mA output (LI56-1211*)
4 relays & 4-20 mA output (LI56-1411*)
Quick Start
