DataView™ LI55 Level Controller

Setting the Decimal Point (

The decimal point may be set to as many as five decimal places. Use
the Decimal Point feature to position the decimal point for all values
displayed. Placement of the decimal point can influence the displayed
output of your process. For example, setting a scale of 0 to 100% can
be shown in four different methods:
Method #1 0% to 100%
Method #2 0.0% to 100.0%
Method #3 0.00% to 100.00%
Method #4 0.000% to 100.000%
When selecting a decimal point, take into account the practical scale for
reading the level of liquid.
To set the decimal point:
1. Press the MENU button to bring up the Main Menu. Units (unitS)
will be the first operation available.
2. Press the Up button to scroll through menu options until you reach
Decimal Point (dEc Pt).
3. Press ENTER button to enter Decimal Point. The current setting will
appear.
4. Press the Right button to move the decimal point from left to right.
a. Note: The decimal point may be set with up to five
decimal places or with no decimal point at all. Pressing
the Right arrow moves the decimal point one place to the
right until no decimal point is displayed, and then it moves
to the left most position.
5. When the decimal is set where you like, press ENTER button to
save this setting.
6. Press MENU button to exit.
20 | P a g e
)
dEc pt
Reads to the ones place and is not very
accurate.
Reads to the 1/10's place and provides good
accuracy.
Reads to the 1/100's place. The accuracy is very
good but may not be practical.
Reads to the 1/1000's place. This is highly
accurate but may not be practical.
