(2) COMS Mode selection(JCMOS1)
Function
Keep CMOS Data(1-2)(Default)
Clear CMOS Data(2-3)
(3) ATX/AT Mode Selection (PSON1)
Function
AT Mode(1-2)
ATX Mode
EPC-U2117 User Manual
Jumper Setting
Jumper Setting
24
