mSATA:
Pin Signal
1 Reserved
3 Reserved
5 Reserved
7 Reserved
9 GND
11 Reserved
13 Reserved
15 GND
17 Reserved
19 Reserved
21 DETECT#
23 RX+
25 RX-
27 GND
29 GND
31 TX-
33 TX+
35 GND
37 GND
39 +3.3V
41 +3.3V
43 Reserved
45 Reserved
47 Reserved
49 Reserved
51 MSATA_DETECT#
EPC-U2117 User Manual
Pin Signal
2 +3.3V
4 GND
6 +1.5V
8 Reserved
10 Reserved
12 Reserved
14 Reserved
16 Reserved
18 GND
20 Reserved
22 Reserved
24 +3.3V
26 GND
28 +1.5V
30 SMB_CLK
32 SMB_DATA
34 GND
36 Reserved
38 Reserved
40 GND
42 Reserved
44 Reserved
46 Reserved
48 +1.5V
50 GND
52 +3.3V
