- Page 1 User Manual 用戶手冊 EPC-U3233 電腦...
- Page 2 If an Advantech product is defective,it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials,service time and freight.
- Page 3 3. If your product is diagnosed as defective, obtain an RMA (return merchandise authorization) number from your dealer. This allows us to process your return more quickly. 4. Carefully pack the defective product, a fully-completed Repair and Replacement Order Card and a photocopy proof of purchase date (such as your sales receipt)in a shippable container.
- Page 4 Declaration of the Presence Condition of the Restricted Substances Markings 用物質含有情況標示聲明書 PLM: TBD 設備名稱： 電腦 型號（型式）： EPC-U3233(系列型號請參照次頁) Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻 多溴聯苯 多溴二苯醚 單元 Ｕnit 鉛 汞 鎘 Lead Mercury Cadmium...
- Page 5 Declaration of Conformity 符合性聲明 FCC Class B (FCC B 級) Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 6 Technical Support and Assistance 技術支援與服務 Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 7 If one of the following situations arises, get the equipment checked by service personnel: The power cord or plug is damaged. Liquid has penetrated into the equipment. The equipment has been exposed to moisture. The equipment does not work well, or you cannot get it to work according to the user's manual.
- Page 8 限制進入區域：本設備應安裝在限制進入區域。 Order Information 訂購資訊 PART NUMBER DRAM WiFi module Adapter 型號 中央處理器 記憶 固態硬碟 作業系統 WiFI 模組 Port 變壓器 體 EPC-U3233-WR074S0 i7-8665UE 16GB NVMe 128GB None (EWM-W192K2) EPC-U3233-WR054S0 i5-8365UE NVMe 128GB Win10 IoT (EWM-W192K2) EPC-U3233-WF054S0 i5-8365UE NVMe 128GB Ubuntu 20.04...
- Page 9 Overview 產品簡介 EPC-U3233 is fanless palm-sized embedded PC powered by the 8th-gen Intel® Core™ i series processor aimed at edge AI computing in industrial environment. EPC-U3233 optimized chassis design achieve easy rapid configuration. EPC-U3233 combines diverse I/O ports and plenty M.2 expansion slot to fulfill multi-functional edge computing ability.
- Page 10 系統組態 1.2 I/O Placement...
- Page 11 General Specifications 一般規格 1.3.1 Function Spec 功能規格 CPU 中央處理器：Intel® Gen-8 Core™ i系列 BIOS 基本輸入輸出系統：AMI EFI 16bit Memory 記憶體：DDR4 SODIMM 2666 MHz，高達 16GB Audio 音訊：HD 音訊解碼器 ALC892 LAN 有線網路：PCI-E gIGABIT 乙太網控制器 x2 USB 介面：2x USB3.0, 2x USB2.0 ...
- Page 12 Environment Specifications (環境規格) Operating Temperature (工作溫度)：0 ~ 50°C Storage Temperature (儲存溫度)：-40 ~ 85°C Relative Humidity (相對濕度)：40 ~ 95% RH non-condensing（非凝結） Satety (安規) CE/CCC/BSMI (電磁相容性) CE/FCC Class B, (CE/FCC B級) Vibration (振動) With SSD：3Grms，60068-2-64，randon，5 ~ 500 Hz，1 hr/axis...
- Page 13 2.1 Module Installation in Top Cover Side 安裝上蓋側模組 Release the screws of the top ocver. 擰開螺絲後卸下上蓋。 Install the SIM, 2242/3042 M.2 module with the screws which in accessory box, SODIMM by demand. Paste the relative the thermal pad to the module(s). 依所需安裝SIM卡、2242/3042 M.2，使用配件盒中螺絲鎖固...
- Page 14 2.2 Module Installation in Bottom Cover Side 安裝底蓋側模組 Release the screws of the bottom cover. 擰開螺絲後卸下底蓋 Install the M.2 module(s)by demand with the screws in the accessory box, and paste the relative thermal pad. 安裝所需M.2模組，使用配件盒中螺絲鎖固，貼附配件盒中模組相對應之散熱片。 Recover the bottom cover and secure the screws. 裝回底蓋，並鎖回底蓋螺絲。...
- Page 15 使用前請檢查核實產品的規格。本手冊僅作為參考。 產品規格如有變更，恕不另行通知。 未經研華公司書面許可，本手冊中的所有內容不得通過任何途徑以任何形式複製、翻 印、翻譯或者傳輸。 所有其他產品名或商標均為各自所屬方的財產。 © 研華公司 2020...
