Pwrbtn#/ Reset#/Hdd Led/ Power Led Header(Jfp1); Sata Power Header (Sata_Pwr1); Sata Signal Connector (Sata1) - Advantech EPC-U2117 User Manual

2.2.21

PWRBTN#/ RESET#/HDD LED/ power LED header(JFP1)

Pin Signal
1 HDD LED+
3 HDD LED-
5 PWR LED+
7 PWR LED-
2.2.22

SATA power header (SATA_PWR1)

Pin Signal
1 +V5
2 GND
2.2.23

SATA signal connector (SATA1)

Pin
1
2
3
4
5
6
7
Pin
2
4
6
8
Pin
3
4
Signal
GND
TX+
TX-
GND
RX-
RX+
GND
17
Signal
PWR_BTN+
PWR_BTN-
RST_BTN+
RST_BTN-
Signal
GND
+12V
EPC-U2117 User Manual
