Summary of Contents for Advantech ES-200-77
- Page 1 ES-200-77 Multimedia Pentium III processor-based computer for HMI Applications User's Manual...
-
Page 2: Copyright Notice
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. -
Page 3: Safety Instructions
Safety Instructions Read these safety instructions carefully. Keep this User’s Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. -
Page 4: Packing List
If any of these items are missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance 1. Visit the Advantech web sites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. -
Page 5: Table Of Contents
Introduction.....................2 How to use this menu................3 Specification ...................4 Dimensions.....................5 Chapter 2 System Setup ................9 Introduction...................10 Quick Tour of ES-200-77..............10 Preparing for the initial use ..............10 Installation Procedure................11 Chapter 3 Using ES-200-77 ..............16 3.1 Introduction 3.2 Hard Drive 3.3 CD-ROM Drive 3.4 PS/2 Mouse and Keyboard... -
Page 6: General Information
Chapter 1 General Information This chapter gives information on ES - 200-77 Sections • • How to Use • •... - Page 7 1.1 General Information The ES-200-77 PC is a multimedia Pentium III processor-based computer that is designed to serve as a human machine interface (HMI) and as a desktop computer. . You can select what application or integration for your system then decide which part you want to apply, or, of course, integrate both as a high performance panel PC.
-
Page 8: Chapter 1 Introduction
PC-104 card, two 3.5” HDDs and multiple display size monitor can be attached as OFPC. With these expansion capabilities, the ES-200-77 does not only function as a system box, but also as a computing center around you to build your application. -
Page 9: Dimensions
Power Specifications: ● Input voltage: AC100-240V, 4-2A, 50-60 Hz ● Output voltage: DC 3.3V =16.8A, 5V = 12A, 12V=10A, 5V=2A, -12V =0.8A ● Output rating: 180W (including ES-200-77 and related DC device). Environment Specifications: ● Operation Temperature: 0~45º C ● Storage Temperature: -20 ~ 60º C ●... -
Page 12: Chapter 2 System Setup
Chapter 2 System Setup Sections include: • A Quick Tour of the Panel PC • Preparing for initial Use • Installation Procedures • Installing the Drivers... -
Page 13: Quick Tour Of Es-200-77
I/O ports, including serial ports, parallel port, the Ethernet port, USB ports, the microphone jack, and so on.) Figure 2-2：ES-200-77 I/O 2.2 Preparing for first-time use Before you start to set up ES-200-77, you should have at least the following items ready: ‧ Power cord (in the accessory box) ‧... -
Page 14: Hard Drive
Connect the PS/2 mouse and keyboard port on the I/O section of the panel PC. 2.3.3 Connecting the display Connect the display to the VGA sub in the bottom of ES-200-77 2.3.4 Switch on the power Switch on the power switch on the rear cover. -
Page 15: Installing The Drivers
These files are a very useful supplement to the information in this manual. Note: The drivers and utilities used for ES-200 are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities. -
Page 16: Ps/2 Mouse And Keyboard
Chapter 3 Using the Panel PC This chapter details installing ES-200 hardware. Sections include: • CD-ROM Drive • PS/2 Mouse and Keyboard • PCI/ISA Bus Expansion • Parallel Port • Serial COM Ports • VGA Port • USB Ports • Audio Interface •... -
Page 17: Pci Bus Expansion
3.1 CD-ROM drive To insert a CD-ROM disc, press the eject button of the CD-ROM drive. The yellow activity light will flash and the front panel will come out a short distance. Using your fingertips, hold the top and bottom of the front panel and pull it outward to the very end. Align the center hole of the CD-ROM disc with the center circle of the CD-ROM holding plate. -
Page 18: Serial Com Ports
PC, and then turn on the panel PC. 5. If necessary, run the panel PC's BIOS setup program to configure the parallel port to respond as required by your printer and software operating environment. 3.5 Serial COM ports There are three serial COM ports on the bottom of the rear cover. You can easily attach a serial device to the panel PC, such as an external modem or mouse. -
Page 19: Ethernet
Line out: Output audio to external devices such as speakers or earphones. Line in: Input audio from an external CD player or radio. 1. Connect the audio device to the system. 2. Install the driver before you use the device. 3.9 Ethernet External devices on your network may be connected to the system through the external Ethernet port located on the rear side of the system unit.
