2.2.12

MCU programming header (JCAN2)

Pin
1
2
3
4
5
2.2.13

CAN BUS header (CAN1)

Pin
1
2
3
2.2.14

Low pin count header (LPC1)

Pin Signal
1 SOC_LPC_AD1
3 SOC_LPC_AD0
5 +V3.3
7 GND
9 NC
EPC-U2117 User Manual
Signal
MCLR#
+V5_CAN
GND
PG_DAT
PG_CLK
Signal
CAN_H1
CAN_L1
GND
Pin
2
4
6
8
10
14
Signal
CLKOUT_25M_LPC
PM_PLTRST#
SOC_LPC_FRAME#
SOC_LPC_AD3
SOC_LPC_AD2
