Chapter 1 Maintenance
10.3

Clearing BIOS Settings (CMOS Memory)

To set the BIOS settings back to the factory default settings (clearing CMOS memory), use the internal jumper
switch.
You can also clear the password set in the BIOS Setup utility (SETUP) by using the same way.
To clear the password or the CMOS memory, use the corresponding jumper switch illustrated in the figure
below.
Clear PASSWORD Jumper
(PASSCLR)
When the server works, use the BIOS setup utility (SETUP) to return the settings to
Tips
the factory defaults.
Important
Do not change any other jumper switch settings. Any change may cause the
server to fail or malfunction.
Protect
(factory default)
Clear
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
10. Resetting the Server and Clearing BIOS Settings
Clear CMOS Jumper
(CMOSCLR)
Protect
(factory default)
Clear
83
