Chapter 2 Configuring and Upgrading the System
The operation such as mounting for a partition of internal hard disk drives must be performed for the RAID
device (md) that is configured by Software RAID but not for partition.
For the ftdiskadm command described later in this document, slot numbers of internal hard disk drives are
allocated as follows;
94
• While the status of each RAID device is RESYNC, RECOVERY, CHECK or
Important
REPAIR, do not insert/remove hard disk drive, power off or restart the system.
Wait until the status turns to DUPLEX. Check the status of RAID device using the
ftdiskadm command. See the Installation Guide for details.
• Use only the hard disk drives specified by NEC. There is a risk of hard disk drive
as well as the server failure when you install a third-party hard disk drive. Use
two, paired hard disk drives of the same model to configure the hard disk drive
redundancy. Ask your sales representative for the hard disk drive appropriate to
this server.
Slot number of hardware
Slot 0 (CPU/IO module 0)
Slot 1 (CPU/IO module 0)
Slot 2 (CPU/IO module 0)
Slot 3 (CPU/IO module 0)
Slot 4 (CPU/IO module 0)
Slot 5 (CPU/IO module 0)
Slot 6 (CPU/IO module 0)
Slot 7 (CPU/IO module 0)
Slot 0 (CPU/IO module 1)
Slot 1 (CPU/IO module 1)
Slot 2 (CPU/IO module 1)
Slot 3 (CPU/IO module 1)
Slot 4 (CPU/IO module 1)
Slot 5 (CPU/IO module 1)
Slot 6 (CPU/IO module 1)
Slot 7 (CPU/IO module 1)
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
Slot number used in ftdiskadm
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
Slot 8
Slot 9
Slot 10
Slot 11
Slot 12
Slot 13
Slot 14
Slot 15
Slot 16
1. Disk Operations
