Chapter 1 Maintenance

4.5.2 Procedure in NEC ESMPRO Manager

Take the steps below to update BIOS of CPU module.
1. Save the BIOS image file for update in the following folder in the server.
/etc/opt/ft/BIOS.ROM
2. Select General screen of the target CPU under the ft System tree in Information of server
state/constitution.
3. Check that the current status of the target component is available. The status is shown on Status
Information display of General screen.
4. Select Update screen and click the Execute button of Firmware Update.
Sample screen of NEC ESMPRO Manager
Important To update BIOS of CPU module, a BIOS image file for updating needs to be stored on
the server.
Update screen of CPU Module
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
4. Maintenance of the Server

35
