Chapter 3 Useful Features
(3)
PCI Configuration submenu
From the Advanced menu, select PCI Configuration and then press the <Enter> key to display the menu
screen as shown below.
For details about the options, see the table below.
Option
SAS Option ROM Scan
LANX Option ROM Scan
PCI Slot X Option ROM
154
Parameter
Disabled
[Enabled]
Disabled
[PXE Boot]
iSCSI Boot
[Disabled]
Enabled
Note For a RAID Controller, LAN card (network boot), or Fibre Channel controller, if no
Hard Disk Drive on which an OS is installed is connected, set the option ROM for
that slot to Disabled.
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
Descriptions
Enable or disable the option ROM SCAN for onboard
SAS.
Enable or disable the option ROM SCAN for onboard
LAN.
R320c-M4 X:1/2/3/4
R320c-E4 X:1/2
Enable or disable the option ROM on each PCI slot.
R320c-M4 X:1/2/3/4
R320c-E4 X:1/2
1. System BIOS
[ ]: Factory settings
