Chapter 2 Configuring and Upgrading the System
12. Install the stopper and secure it with one screw.
13. See Chapter 2 (5.4.2 Installing CPU/IO Module) and install the CPU/IO module.
14. Connect the power cords.
15. Press the POWER switch to power on the server.
16. Verify that POST displays no error message.
If POST displays an error message, write it down and see the POST error message list in Chapter 1 (6.2
POST Error Message).

5.7.3 Removing PCI Card

To remove PCI card card, follow the reverse procedure of the installation and install the slot cover.
142 Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
5. Installing Optional Devices
