Chapter 2 Configuring and Upgrading the System
5. Installing Optional Devices
6. Disconnect cables.
7. Remove the air duct.
Air duct
8. Locate the socket you are mounting the DIMM.
9. Remove the dummy memory module by opening the levers on both sides of the DIMM slot.
Dummy memory module
DIMM socket
Important
Keep and store the removed dummy memory module with care.
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
125
