Chapter 1 Maintenance
After the completion of mirror volume duplication and when the PCI modules are duplicated:
1 PRIMARY LED
2 DISK ACCESS LED
3 System FT LED
LED Secondary
Blinking (Green)
(Lights green when
accessing the disk drive)
LED
On (Green)
Important After duplication is completed, the FT LED lights in green. Do not perform the
evaluation of start and stop unless the above process is completed.
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
5. Checking the Duplicating Operation of Modules
Primary
– On (Green)
Blinking (Green)
(Lights green when
accessing the disk drive)
System
