Procedure In Nec Esmpro Manager - NEC Express5800/R320c-E4 Maintenance Manual

Chapter 1 Maintenance

4.2.2 Procedure in NEC ESMPRO Manager

Perform the procedure below to clear (initialize) MTBF information of component.
1. Select General screen of the target component under the ft System tree in Information of server
state/constitution.
2. Check that the current status of the target component is available. The status is shown on Status
Information display of General screen.
3. Select Maintenance screen and click the Execute button of MTBF Clear operation.
4. Start the target component.
Sample screen of NEC ESMPRO Manager
The MTBF clearing result can be verified by "Status Information" in General on the target
Tips
component screen. The result of the MTBF clearing operation is reported by the server as
an alert.
Maintenance screen of CPU Module
Express5800/R320c-E4, R320c-M4 Maintenance Guide (Linux)
4. Maintenance of the Server

31
