No. Designation
[9] Plug-in terminals
[10] Fieldbus interface
(RJ45 socket)
Terminal Function
X1: Digital ground and housing potential
X1: Electrically isolated output with internal resistor to limit
the current to about 10 mA. An LED can be connected
here as a power status display
X1: Electrically isolated input. Connection of a button to
switch the MOVI‑C
• Pushing the button briefly switches on the deacti-
vated MOVI‑C
• Pushing the button briefly during operation shuts
down the MOVI‑C
• Pushing the button for at least 5 s switches off the
®
MOVI‑C
X1:On Electrically isolated input. Connection of a button to
switch the MOVI‑C
X1:M Common ground for all electrically isolated inputs/out-
puts
X1:− Connection of DC 24 V supply (−)
X1:+ Connection of DC 24 V supply (+)
X21/22 EtherNet/IP™ slave connection
Manual – MOVI-C
Installation notes
Electrical installation
®
CONTROLLER on and off:
®
CONTROLLER
®
CONTROLLER
CONTROLLER
®
CONTROLLER on
®
CONTROLLER power UHX85A
