4.2.5

Virtual network card (VNET)

Apart from the hardware communication connections of the MOVI-C

the Windows 7 operating system is also provided with a virtual network card (VNET).

VNET allows for a very simple addressing of the control section of the

MOVI-C

i.e. in MOVITOOLS

section via the default address 192.168.2.2.

If you do not use the virtual network card (VNET), you have to interconnect the real

network connections of the Windows section (LAN 1) and of the control section (LAN

1) via a network switch.

INFORMATION

The virtual network card (VNET) does not support DHCP operation.

Setting the network addresses

Setting the network address of the Windows section

Set the network addresses of the Windows section with the corresponding settings

menus in the Windows operating system.

Proceed as follows:

1. Click in the Start menu on [Control Panel].

2. Select the "Network and Internet" submenu and then call up the "Network and

CONTROLLER. The virtual network card behaves like a real network card,

MotionStudio, for example, you can directly address the control

Sharing Center" menu.

Installation notes

Manual – MOVI-C

CONTROLLER power UHX85A

Electrical installation

CONTROLLER,

9007207084117259
