Configurations
Cable type 8
Cable type 9
Cable type 10
Cable type 11
Cable type 12
(*) extra cable 1 BNC to 1 BNC 45m 150ft is included with the stereo option in case this stereo option is used in combination with
the long cable option (Z3483105).
The following extra equipment is necessary to set up this configuration :
All these peripherals are mounted in a RACK, and delivered as one unit. The order numbers and quantities are only given as information
for after sales orders.
MAGIC interface
RCVDS05
Quad Splitter
Quad Switcher
VSE40
Stereo emitter
Stereo glasses
Hint
As there is no power switch on the system, use socket strips with power breaker to connect the projectors, audio amplifier, stereo
emitters and the RACK to the wall outlet.
Internal Connections RACK system 2-channel sytem
See 'Internal Connections RACK system 2-channel sytem' under paragraph '2-channel configuration mono with switching option'.
Connection table internal connections RACK system
See 'Connection table internal connections RACK system' under paragraph '2-channel configuration mono with switching option'.
8-34
Connection piece D9 - BNC
5 BNC to 5 BNC 5m 15ft
RS232 communication cable 15m 15ft 5
Audio cable
Audio cable
BNC-BNC coupling pieces
2x R9828121 (230V) or R9828128 (120V) according to the ordered destination kit.
2x R9828700 (230V) or R9828709 (120V) according to the ordered destination kit.
2x R9828300 (230V) or R9828309 (120V) according to the ordered destination kit.
1x R9828311 (230V) or R9828319 (120V) according to the ordered destination kit.
1x R9828520 (230V) or R9828529 (120V) according to the ordered destination kit.
2x R9828221 (230V) or R9828128 (120V) according to the ordered destination kit.
5x R9828223
1 Z3487291
2 Z348332
Z3482602
1
2
8 R313667
