ROOM REQUIREMENTS

Room Requirement

Weight-tolerant
The ground must be flat and horizontal. It should be able to bear the weight of the system.
For wooden floors, if the part receiving the weight of the system lies at the center between the reinforcement beams below the floor,
the floor may become deformed or may curve inwards. In such cases, lay more than 12 mm thick board below the system to distribute
the weight of the system on the floor.
For concrete floors, it may be possible to install the system horizontally due to roughness of the floor. In such cases, do the same
as above.

Airco Requirements

The following specifications for temperature and humidity have to be observed :
Temperature : 17 - 27 °C (62 - 80 F)
Humidity : 40 - 60 % RH
Dust class : 100000 particles per cubic feet

Power Requirements

Minimum power requirements in the room :
2-channel system : 100-240V 15-7A 50-60Hz
3-channel system : 100-240V 28-15A 50-60Hz
Note : when using a power strip, be aware for the maximum current of the power strip. Use a power strip that can support the
above indicated current.
Additional power requirement
3D option : standard power strip and wall outlet.
switching options : standard wall outlet

Lightning

Projection screens do not reflect external light like CRT, but screens and their base materials may still cause reflection if strong light
of spotlight, etc. is directly incident to them. In such case, prevent the illumination lightning from hitting the screen surfaces directly.
Surrounding space
The system can be installed against the wall. However, remember that a space of at least 400mm (16") is required in the maintenance
operation and install the system by taking later maintenance in consideration;
If the system is placed in a niche, remember that a space of at least 800mm (32") is required on one side of the system for set up
and maintenance operation (image 1).
T
p
h
y r
Ã
 !

image 1
Front Space
Finger and hand prints form easily on the face of the screen. Therefore make sure viewers cannot touch it directly. Leave workspace
in front for replacing the screen.
